Control system: touch screen
Remote control: standard wireless remote control, which can remotely control the start, stop, acceleration, deceleration of the grinder and switch between three operating modes (one-way continuous operation, one-way interval operation, two-way alternating interval operation)
Display mode: 7.0-inch color LCD screen, which can display and touch the operation mode, operation time, speed, and alternating operation interval
Operation mode: one-way continuous operation, one-way interval operation, two-way alternating interval operation, timed stop
Continuous operation time setting: 0.1~9999.9 minutes
Alternating and one-way interval pause time setting: 0.1~9999.9 minutes
Main disk speed: 50-550m in
Grinding jar speed: 100-1100min
Transmission ratio (planetary disc, grinding jar): 1:2
Continuous operation (full load): 90h
Emergency stop: The red emergency stop button can be used to shut down the machine with one click
Power-off memory function: The time setting before power failure does not need to be reset after power failure
Overload protection function: Yes
Grinding chamber design: sealed and dustproof, with four-way observation window
Number of samples processed at the same time: 4/2
Applicable grinding jars: This machine is a new general-purpose type, and three specifications of grinding jars of 100ml, 250ml, and 500ml can be used. Jars of different specifications can be placed at the same time according to customer needs; diagonal symmetry is sufficient (4 grinding jars are a set).
Maximum sample size: 12mm for soil, 3mm for others
Grinding jar ball quantity: one-third of the jar volume
Maximum sample loading: two-thirds of the grinding jar volume
Sample size: minimum 0.1um (i.e. 1.0×10mm-4)
Grinding jar material: agate, ceramic, polytetrafluoroethylene, zirconium oxide, polyurethane, stainless steel, nylon, tungsten carbide, cemented carbide, etc. (commonly used agate and zirconium oxide grinding jars)
Grinding ball material: agate, zirconium oxide, stainless steel, ceramic, cemented carbide, silicon carbide, etc.
Grinding ball diameter: 3, 5, 10, 15, 20mm (configured according to actual needs)
Motor speed, power, voltage: 1400rpm, 0.75kw, 220V±10% single phase, 50/60Hz
